Name: Borsinda Kawasaki K3V112DT Rotary kits for Hyundai R210-7 Hydraulic Pump Repair Kits
Brand: BORSINDA
SKU: 369
Availability: InStock
Rating: 5.0 (153 reviews)

BORSINDA Kawasaki K3V112DT Rotary kits for Hyundai R210-7 Hydraulic pump Repair Kits

Part No: K3V112DT, 31N6-10010,31N6-10050,31N6-10051

Application: Hyundai excavator R210LC-7, R220LC-7,RC215C7,RD220-7,R215-7,R220-5,R225-7,R210LC-9,R220LC-9,R235LC-9

No.	Part No	Qty	Parts name
*.	31N6-10010	[1]	MAIN PUMP ASSY
*.	31N6-10050	[1]	MAIN PUMP ASSY
*.	31N6-10051	[1]	MAIN PUMP ASSY
*-1.	@	[1]	MAIN PUMP UNIT
111	XJBN-00077	[1]	DRIVE SHAFT(F)
113	XJBN-00078	[1]	DRIVE SHAFT(R)
114	XJBN-00351	[1]	COUPLING-SPLINE
123	XJBN-00079	[2]	BEARING-ROLLER
123	XJBN-00950	[2]	BEARING-ROLLER
124	XJBN-00080	[2]	BEARING-NEEDLE
127	XJBN-00081	[4]	SPACER-BEARING
NS141.	XJBN-00067	[2]	BLOCK-CYLINDER
NS151.	XJBN-00061	[18]	PISTON
NS152.	XJBN-00062	[18]	SHOE
*-11.	XJBN-01116	[1]	SET PLATE KIT
153	XJBN-00082	[2]	PLATE-SET
156	XJBN-00353	[2]	BUSHING-SPHERICAL
156	XJBN-00083	[2]	BUSHING-SPHERICAL
158	XJBN-00354	[2]	SPACER
157	XJBN-00084	[18]	SPRING-CYLINDER
211	XJBN-00085	[2]	PLATE-SHOE
NS212.	XJBN-00070	[2]	PLATE-SWASH
S214.	XJBN-00071	[2]	BUSHING-TILTING
251	XJBN-00086	[2]	SUPPORT
261	XJBN-00087	[1]	COVER(F)-SEAL
271	XJBN-00088	[2]	CASING-PUMP
312	XJBN-00089	[1]	BLOCK-VALVE
S313.	XJBN-00065	[1]	PLATE-VALVE(R)
S314.	XJBN-00068	[1]	PLATE-VALVE(L)
401	XJBN-00090	[8]	SCREW-HEX SOC HD
406	XJBN-00355	[4]	SCREW-HEX SOC HD
466	XJBN-00356	[2]	PLUG
468	XJBN-00357	[4]	PLUG
490	XJBN-00032	[18]	PLUG
NS531.	XJBN-00358	[2]	PIN-TILTING
532	XJBN-00091	[2]	PISTON-SERVO
534	XJBN-00092	[2]	STOPPER(L)
535	XJBN-00093	[2]	STOPPER(S)
NS541.	XJBN-00073	[4]	SEAT
NS541.	XJBN-00859	[4]	SEAT
NS543.	XJBN-00074	[2]	STOPPER 1
NS543.	XJBN-00860	[2]	STOPPER
NS544.	XJBN-00076	[2]	STOPPER 2
NS544.	XJBN-00861	[2]	STOPPER
S545.	XJBN-00359	[4]	BALL-STEEL
NS548.	XJBN-00360	[2]	PIN-FEED BACK
K702.	XJBN-00918	[2]	O-RING
K710.	XJBN-00095	[1]	O-RING
K717.	XJBN-00096	[4]	O-RING
K724.	XJBN-00361	[16]	O-RING
K725.	XJBN-00362	[4]	O-RING
K728.	XJBN-00363	[4]	O-RING
K732.	XJBN-00912	[2]	O-RING
K774.	XJBN-00098	[1]	SEAL-OIL
789	XJBN-00099	[2]	RING-BACK UP
792	XJBN-00100	[2]	BACK-UP RING
806	XJBN-00101	[2]	NUT
808	XJBN-00364	[2]	NUT
824	XJBN-00102	[2]	RING-SNAP
885	XJBN-00103	[2]	PIN-VALVE PLATE
886	XJBN-00365	[4]	PIN-SPRING
901	XJBN-00104	[2]	BOLT-EYE
953	XJBN-00105	[2]	SCREW-SET
954	XJBN-00106	[2]	SCREW-SET
981	XJBN-00156	[1]	NAME PLATE
981	XJBN-00391	[1]	NAME PLATE
983	XJBN-00341	[2]	PIN
*-2.	@	[1]	REGULATOR
*-3.	@	[1]	Gear pump
*-4.	@	[1]	EPPR VALVE
11	XJBN-00060	[2]	PISTON SUB ASSY
13	XJBN-00063	[1]	CYLINDER ASSY(RH)
14	XJBN-00066	[1]	CYLINDER ASSY(LH)
30	XJBN-00069	[2]	SWASH PLATE SUB ASSY
41	XJBN-00072	[2]	CHECK VALVE ASSY 1
42	XJBN-00075	[2]	CHECK VALVE ASSY 2
530	XJBN-00366	[2]	TILTING PIN ASSY
K.	XJBN-00971	[1]	PUMP UNIT SEAL KIT

Product Models:	Borsinda K3V112DT Rotary Group Kits
Place of Origin:	China
Packaging Details:	PP bag, Carton, Wooden cx, or as Required
Delivery Time：	1-7 work days
Payment Terms：	T/T, L/C, Alipay, Deposit, PayPal, D/P
